The Acer PL series projectors offer stunning picture quality, life-like colors, and incredible efficiency thanks to the innovative laser diode. Beyond picture quality, the PL projectors' laser diodes have a long lifespan. With no lamp to burn out, it greatly reduces lamp replacement costs and hassle. The laser light engine is also mercury-free, eliminating the potential pollution from mercury lamp disposal and making it the environmentally friendly choice.
Special Features
Product features
Product Specification
| Device Type | DLP projector - 1080p |
| Localisation | EMEA |
| Microdisplay | DarkChip 3 |
| Brightness | 5500 ANSI lumens |
| Brightness (Reduced) | 4400 ANSI lumens |
| Contrast Ratio | 2000000:1 (dynamic) |
| Image Size | 53 cm - 762 cm |
| Projection Distance | 1 m - 9 m |
| Throw Ratio | 1.4 - 2.24:1 |
| Uniformity | 80 % |
| Digital Zoom Factor | 2x |
| Resolution | WUXGA - WUXGA (1920 x 1200) |
| Native Aspect Ratio | 16:10 |
| Colour Support | 1.07 billion colours |
| Max Sync Rate (V x H) | 120 Hz x 100 kHz |
| Bulb type | Laser diode |
| Bulb life cycle | Up to 20000 hour(s) - normal mode ¦ Up to 30000 hour(s) - economic mode |
| Features | High-bandwidth Digital Content Protection System (HDCP), wall colour correction, Instant Pack Technology, DLP 3D Ready, Auto Vertical Keystone, SmartFormat Technology, 16:9 aspect ratio support, 4:3 aspect ratio support, 360° projection, auto shutdown, Customisable Startup Display, HDMI Power On, HDMI 3D ready, Loop Through, PIN security |
| Lens Aperture | F/2.5-3.26 |
| Zoom Factor | 1.6x |
| Keystone Correction Direction | Horizontal, vertical |
| Vertical Keystone Correction | -30 / +30 |
| Horizontal Keystone Correction | -30 / +30 |
| Lens Shift Type | Manual |
| Lens Shift Direction | Vertical |
| Vertical Lens Shift | 99% / 107% |
| Video Interfaces | VGA, HDMI, composite video, S-Video, MHL, HDBaseT |
| Video Modes | 1080p |
| LAN and Wireless Image Transferring Protocols | Wired LAN |
| Type | Integrated |
| Sound Output Mode | Stereo |
| Output Power / Channel | 10 Watt |
| Speakers | 2 x right / left channel |
| Interfaces | 1 x Mobile High-Definition Link (MHL) / HDMI ¦ 1 x HDMI - 19 pin HDMI Type A ¦ 2 x VGA - 15 pin HD D-Sub (HD-15) ¦ 1 x composite video input - RCA ¦ 1 x S-video input ¦ 1 x audio line-in ¦ 1 x microphone input ¦ 1 x network - RJ-45 ¦ 1 x HDBaseT ¦ 1 x serial RS-232 (management) ¦ 1 x USB - 4 pin USB Type A ¦ 1 x audio line-out ¦ 1 x VGA output |
| Included Accessories | Lens cover, wireless remote control |
| Cables Included | 1 x HDMI cable - 1.8 m |
| Security Features | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Power Source | AC |
| Power Consumption Operational | 321 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Width | 37.4 cm |
| Depth | 30.2 cm |
| Height | 11.7 cm |
| Weight | 6 kg |
| Shipping Width | 52 cm |
| Shipping Depth | 42.5 cm |
| Shipping Height | 22.5 cm |
| Shipping Weight | 8.3 kg |
| Service & Support | Limited warranty - 3 years - pick-up and return ¦ Limited warranty - DLP chipset - 5 years |
| Sound Emission | 31 dB |
| Sound Emission (Economic Mode) | 28 dB |
See crystal-clear, vibrant images from a distance in lecture halls, auditoriums or any large venues with up to 5,500 lumens of brightness.
Enjoy life-like colors and never worry about lamp burn-out or disposal with the innovative laser diode, using 30% less power at the same brightness.
Enjoy long-lasting brightness with a laser light source, providing consistent performance for up to 8 times longer than lamp-based models.
Rotate this projector 360 degrees in any direction and still get accurate images in spaces where a little more flexibility is required.
Use this projector as often as you like and for as long as you like; with a 30,000-hour lifetime[3], you won't be needing a replacement any time soon.
This projector handles continuous day in, day out use - ideal for public displays and exhibitions.
Never miss out on fabulous new content as this projector takes a 4K HDR Rec. 2020 signal and correctly transfers it into its native resolution.
Eliminate cable clutter with HDBaseT™[2], the global standard for transmitting UHD video, audio, Ethernet and more through a single cable.
Get greater flexibility and project in a variety of spaces with Portrait Mode[1], which allows the projector to be installed with one side facing down.
